RFT Z563C Dekatron Tube
Written by AnubisTTP on 2011-02-19

Description

The Z563C is RFT's counting only variant of the Z562S selector tube shown above. This tube has the same envelope and identical stats to the Z562S; a 5kHz maximum counting speed with a neon fill gas. Unlike the Z562S which has a 13 pin base, this tube has a standard 9 pin 'Magnoval' base, and uses commonly available sockets. Four of the pins on the base are stubs and not connected to anything, this tube has only a single output cathode.

RFT Z563C Datasheet (PDF)

More

RFT Z563C
RFT Z563C dekatron tube, normal operation. The Z563C is filled with neon and has a maximum counting speed of 5kHz.
